| Resistance Range - Milli and Microhm Meters |
0 to 2500 ohm |
| Resolution |
0.1u Ohms |
| Accuracy |
+/-0.2% |
| Output Current |
0.1mA to 10A |
| Resistance Range |
0 to 2500 ohm |
| Display |
Backlit LCD |
| Features |
Heavy Duty Case, High or Low Output Power |
| Power Source |
Battery |
| Safety Rating |
Cat III 300 V |
| Includes |
4 ft DH4 Duplex Handspike, CD User Guide, Lid Mounted Lead Pouch |
| Counts |
25,000 |
| Auto Power Off |
Yes |
| Calibration Certificate |
Not Included |
| Auto Ranging |
Yes |
| Includes Batteries |
Yes |
| Dustproof |
Yes |
| USB Data Download Included |
No |
| Remote Control Compatible |
No |
| Data Logger |
Yes |
| Testing Functions |
Low Resistance |
| Bluetooth Compatible |
No |
| Low Resistance Range |
0 to 2.5 kilohm |
| Maximum Insulation Resistance |
250 microohm |
| Number of Digits |
5 |
| Resistance Accuracy |
+/-0.20% |
| Maximum AC Voltage Measured |
240 V |
| CAT Safety Rating |
CAT III 300V |
| Test Current |
100 uA to 10 A |
| Waterproof |
Yes |
| IP Rating |
IP54; IP65 |
| Minimum Ground Resistance Measurement |
250 milliohm |
| Tester Type |
Micro Ohmmeter |
| Operating Voltage |
600V |
| Insulation Resistance Resolution |
0.01 milliohm to 0.1 ohm |
| Minimum AC Voltage Measured |
240 V |
| Number of Batteries Required |
1 |
| Minimum Operating Temperature |
14 Degrees F |
| Battery Chemistry |
Lead Acid |
| Minimum Insulation Resistance |
0 kiloohm |
| Asset Tagging |
No |
| Maximum Operating Temperature |
122 Degrees F |
| Alert Type |
Digital Display |
| Display Screen Type |
LCD with Backlight |
| Number of Records Stored |
220 |
| Maximum Ground Resistance Measurement |
2.5 ohm |
| Display Type |
Digital |
| Input Impedance |
200 kiloohm |
| Maximum Operating Temperature |
122 Degrees F |
